BMA diffusers – getting the maximum

Every sugar campaign aims for maximum output. All the better, if a simple but reliable process can be used already at the juice extraction stage: diffusion. In many up-to-date sugar factories, diffusers from BMA are therefore the state of the art.

Request now
Same process, new application
Maximum extraction rates

Maximum extraction rates

Diffusers from BMA are used to extract raw juice with the highest possible sugar concentration from mechanically broken down sugar cane, to permit economically viable processing. With our diffusers, it is possible to optimise parameters such as the retention time, the volume-to-throughput ratio, the amount of fresh water and the concentration gradient. Reduced Extraction Rates of up to 98.5 percent are the result.

Easy and cost-effective installation and operation

The diffusers from BMA are based on simple yet reliable functional and design concepts. With only a small number of complex components, many parts can be manufactured locally. Wear and tear has been reduced with the use of fewer movable components. In addition, many standard assemblies are used. All this helps to cut costs while achieving excellent technological results. The simple and thus reliable diffusion process combined with a high level of automation means far fewer operating staff are required, particularly compared to the milling train.

Greater potential for co-generation

With their central drive, small pumps and few movable parts, diffusers from BMA require less energy. Which means that every kilowatt hour (kWh) saved can be sold!

Request now

The key benefits of diffusers from BMA at a glance

  • Maximum extraction rates of up to 98.5 %
  • Low investment, operating and maintenance costs
  • High share of locally manufactured parts
  • High potential for co-generation thanks to low energy requirement
  • Juice with low suspended solids
  • Low contamination risk
  • Further reduction of sugar losses with mud recycling
  • Low level of residual moisture in the bagasse
  • Outdoor installation possible
A step ahead with new ideas
we-care-green-icon

Save energy with a BMA Diffuser

For a factory crushing 10000 tonnes of cane per day, the average power consumption for diffusion process is 1.8 MW including the milling unit used as dewatering mill. In contrast, a milling train, comprising of 5 mills, would consume 4.5 MW to process the same cane rate. The power savings could be exported to the grid or transferred into bagasse savings for other value-added products.

Downloads

Please refer to the product brochure for more detailed information. We would also be happy to advise you in a personal consultation.

BMA brochure "BMA Beet Extraction"
